CHAPTER 8
Port and Interface Specifications
•
USB Port Specifications for an EX Series Switch on page 43
•
Cable Specifications for Console and Management Connections for the
EX4600 on page 44
•
Console Port Connector Pinout Information for an EX Series Switch on page 45
•
Interface Support for an EX4600 Switch on page 46
•
Interface Specifications for SFP, SFP+, and QSFP+ Transceivers for the EX4600
Switch on page 49
•
Interface Specifications for SFP+ DAC Cables for the EX4600 Switch on page 60
•
Interface Specifications for QSFP+ DAC Breakout Cables for the EX4600
Switch on page 65
•
Interface Specifications for QSFP+ DAC Cables for the EX4600 Switch on page 68
USB Port Specifications for an EX Series Switch
The following Juniper Networks USB flash drives have been tested and are officially
supported for the USB port on all EX Series switches:
•
RE-USB-1G-S
•
RE-USB-2G-S
•
RE-USB-4G-S
CAUTION: Any USB memory product not listed as supported for EX Series
switches has not been tested by Juniper Networks. The use of any
unsupported USB memory product could expose your EX Series switch to
unpredictable behavior. Juniper Networks Technical AssistanceCenter(JTAC)
can provide only limited support for issues related to unsupported hardware.
We strongly recommend that you use only supported USB flash drives.
All USB flash drives used on EX Series switches must have the following features:
•
USB 2.0 or later.
•
Formatted with a FAT or MS-DOS file system.
43Copyright © 2014, Juniper Networks, Inc.
