Juniper EX4600 Series

Table 24: SFP+ Active Direct Attach Copper Cable Specifications
SpecificationsProduct Number
10-Gbps full-duplex serial transmissionRateQFX-SFP-DAC-1MA
Copper pigtailConnector type
3.3 VSupply voltage
0.627 WPower consumption (per end)
–40
°
C to 85
°
CStorage temperature
TwinaxCable type
30 AWGWire AWG
1 in. (2.54 cm)Minimum cable bend radius
100 ohmsCable characteristic impedance
2% maximumCrosstalk between pairs
1 m (3.3 ft)Length
10-Gbps full-duplex serial transmissionRateQFX-SFP-DAC-3MA
Copper pigtailConnector type
3.3 VSupply voltage
0.627 WPower consumption (per end)
–40
°
C to 85
°
CStorage temperature
TwinaxCable type
30 AWGWire AWG
1 in. (2.54 cm)Minimum cable bend radius
100 ohmsCable characteristic impedance
2% maximumCrosstalk between pairs
3 m (9.9 ft)Length
63Copyright © 2014, Juniper Networks, Inc.
Chapter 8: Port and Interface Specifications
