CHAPTER 9
Cable Specifications
•
Network Cable Specifications for EX4600 Switches on page 73
•
Cable Specifications for Console and Management Connections for the
EX4600 on page 74
•
Understanding EX Series Switches Fiber-Optic Cable Signal Loss, Attenuation, and
Dispersion on page 74
•
Calculating the EX Series Switch Fiber-Optic Cable Power Budget on page 76
•
Calculating the EX Series Switch Fiber-Optic Cable Power Margin on page 76
Network Cable Specifications for EX4600 Switches
EX4600 switches have interfaces that use various types of network cables.
Table 29 on page 73 lists the specifications forthe cables that connect the console (CON)
and management (MGMT) ports to management devices.
NOTE: The EX4600 can be configured with SFP management ports that
support 1000BASE-SX transceivers. See “Interface Specifications for SFP,
SFP+, and QSFP+ Transceivers for the EX4600 Switch” on page 49 for more
information about the fiber-optic cables required for use with these
transceivers.
Table 29: Cable Specifications for Switch-to-Management-Device Connections
Additional
Information
Switch
ReceptacleMaximum Length
Cable/Wire
Supplied
Cable
Specification
Ports on EX4600
Switches
“Connecting an EX
Series Switch to a
Management
Console” on
page 153
RJ-457 ft (2.13 m)One 7-foot
(2.13-meter)
lengthRJ-45 patch
cable and RJ-45 to
DB-9 adapter
RS-232 (EIA-232)
serial cable
RJ-45 Console
(CON) port
Connecting an EX
Series Switch to a
Network for
Out-of-Band
Management
RJ-45328 feet
(100 meters)
One 7-foot
(2.13-meter)
lengthRJ-45 patch
cable
Category 5 cable
or equivalent
suitable for
1000BASE-T
operation
Management
(MGMT) Ethernet
port
(10/100/1000)
73Copyright © 2014, Juniper Networks, Inc.
