Juniper EX4600 Series User Manual

Table 15: Cabinet Requirements for the EX4600 Switch
GuidelinesCabinet Requirement
The minimum cabinet size for accommodating a EX4600 switch is 36 in. (91.4 cm)
deep. Large cabinets improve airflow and reduce the chance of overheating.
Cabinet size and clearance
When you mount the switch in a cabinet, ensure that ventilation through the cabinet
is sufficient to prevent overheating.
•
Ensure that the cool air supply you provide through the cabinet adequately
dissipates the thermal output of the switch (or switches).
•
Ensure that the cabinet allows the chassis hot exhaust air to exit the cabinet
without recirculating into the switch. An open cabinet (without a top or doors)
that employs hot air exhaust extraction from the top allows the best airflow
through the chassis. If the cabinet contains a top or doors, perforations in these
elements assist with removing the hot air exhaust.
•
The EX4600 fans exhaust hot air either through the vents on the port panel or
through the fans and power supplies. Install the switch in the cabinet in a way
that maximizes the open space on the FRU side of the chassis. This maximizes
the clearance for critical airflow.
•
Route and dress all cables to minimize the blockage of airflow to and from the
chassis.
•
Ensure that the spacing of rails and adjacent cabinets allows for the proper
clearance around the switch and cabinet.
Cabinet airflow requirements
Related
Documentation
Clearance Requirements for Airflowand Hardware Maintenance for an EX4600 Switch
on page 41
•
• Rack Requirements for an EX4600 Switch on page 39
• Mounting an EX4600 Switch in a Rack or Cabinet on page 141
Clearance Requirements for Airflow and HardwareMaintenanceforan EX4600 Switch
When planning the site for installing an EX4600 switch, you must allow sufficient
clearance around the installed chassis (see Figure 15 on page 42).
41Copyright © 2014, Juniper Networks, Inc.
Chapter 7: Rack and Cabinet Requirements
* Optics, Fans and Power supply sold separately for EX4600-40F-S.

Juniper EX4600 Series Specifications

General

Product Series	EX4600
10GbE ports	24 or 48
Cooling	Front-to-back or back-to-front airflow
Rack Units	1 U
Virtual Chassis	Up to 10 members
MAC address table size	288, 000 entries
Memory	8 GB DRAM
Layer 3 Routing	Yes
AC Power Input	100-240V AC
Ports	24 or 48 x 10GbE ports
40GbE ports	4
100GbE ports	0
Power Supply	Dual redundant, hot-swappable AC or DC
Jumbo frames	9216 bytes
Operating temperature	0°C to 45°C
Input voltage	100-240 VAC, -40 to -72 VDC
Operating relative humidity	5% to 90% noncondensing
Fans	Redundant
JUNOS OS	Junos OS
Storage	16 GB flash
DC Power Input	-40 to -72 VDC
