Juniper EX4600 Series User Manual

CHAPTER 10
Planning Power Requirements
•
AC Power Specifications for an EX4600 Switch on page 79
•
AC Power Cord Specifications for an EX4600 Switch on page 79
•
DC Power Specifications for an EX4600 Switch on page 81
AC Power Specifications for an EX4600 Switch
Table 32 on page 79 describes the AC power specifications for an EX4600 switch.
Table 32: AC Power Specifications for an EX4600 Switch
SpecificationItem
Operating range: 100–240 VACAC input voltage
50–60 HzAC input line frequency
•
4.5 A at 100–120 VAC
•
2.0 A at 200–240 VAC
AC input current rating
Typical power consumption: 230 W
Maximum power consumption: 365 W
Related
Documentation
AC Power Cord Specifications for an EX4600 Switch on page 79•
• AC Power Supply in an EX4600 Switch on page 23
• General Safety Guidelines and Warnings on page 91
• General Electrical Safety Guidelines and Warnings on page 119
AC Power Cord Specifications for an EX4600 Switch
Detachable AC power cords are shipped with the chassis, if you include them as part of
your order. The coupler is type C13 as described by International Electrotechnical
Commission (IEC) standard 60320. The plug at the male end of the power cord fits into
the power source outlet that is standard for your geographical location.
79Copyright © 2014, Juniper Networks, Inc.

Juniper EX4600 Series Specifications

General

Product Series	EX4600
10GbE ports	24 or 48
Cooling	Front-to-back or back-to-front airflow
Rack Units	1 U
Virtual Chassis	Up to 10 members
MAC address table size	288, 000 entries
Memory	8 GB DRAM
Layer 3 Routing	Yes
AC Power Input	100-240V AC
Ports	24 or 48 x 10GbE ports
40GbE ports	4
100GbE ports	0
Power Supply	Dual redundant, hot-swappable AC or DC
Jumbo frames	9216 bytes
Operating temperature	0°C to 45°C
Input voltage	100-240 VAC, -40 to -72 VDC
Operating relative humidity	5% to 90% noncondensing
Fans	Redundant
JUNOS OS	Junos OS
Storage	16 GB flash
DC Power Input	-40 to -72 VDC
