CHAPTER 7
Rack and Cabinet Requirements
Rack Requirements for an EX4600 Switch on page 39
Cabinet Requirements for an EX4600 Switch on page 40
Clearance Requirements for Airflow and Hardware Maintenance for an EX4600
Switch on page 41
Rack Requirements for an EX4600 Switch
EX4600 Switches are designed to be installed on four-post racks.
Rack requirements consist of:
Rack type
Mounting bracket hole spacing
Rack size and strength
Table 14 on page 39 provides the rack requirements and specifications for the EX4600
Switch.
Table 14: Rack Requirements for the EX4600 Switch
GuidelinesRack Requirement
Use a four-post rack that provides bracket holes or hole patterns spaced at 1 U (1.75 in. or 4.45 cm)
increments and that meets the size and strength requirements to support the weight.
A U is the standard rack unit defined in Cabinets, Racks, Panels, and Associated Equipment (document
number EIA-310–D) published by the Electronics Industry Association.
Rack type
The holes in the mounting brackets are spaced at 1 U (1.75 in. or 4.45 cm), so that the switch can be
mounted in any rack that provides holes spaced at that distance.
Mounting bracket hole
spacing
39Copyright © 2014, Juniper Networks, Inc.
