Table 3: EX4600 Switch Product Numbers (continued)
Airflow
Power
Supply
Number of
Expansion
ModulesPortsProduct Number
Air Out (port to FRU)DC224 SFP+ and 4 QSFP+
EX4600-40F-DC-AFO
QFX5100-24S-DC-AFO
CAUTION: Mixing different types (AC and DC) of power supplies in the same
chassisis not supported.Mixing different airflowmodulesin the same chassis
is not supported.
Related
Documentation
Management Panel of an EX4600 Switch on page 9•
• Port Panel of an EX4600 Switch on page 11
• EX4600 Switch Hardware Overview on page 3
Field-Replaceable Units in an EX4600 Switch
Field-replaceable units (FRUs) are components that you can replace at your site. The
EX4600 switch FRUs are hot-insertable and hot-removable:you can removeand replace
them without powering off the switch or disrupting the switching function.
CAUTION: Replace a failed power supply with a blank panel or new power
supply within one minute of removal to prevent chassis overheating. The
switch continues to operate with only one power supply running. Replace a
failed fan module with a new fan module within one minute of removal to
prevent chassis overheating. Do not operate the switch with missing FRUs
for longer than one minute.
Table 4 on page 6 lists the FRUs for the EX4600 switch and actions to take before
removing them.
Table 4: FRUs in a EX4600 Switch
Required ActionFRU
None.Power supplies
None.Fan modules
None. We recommend that you disable the interface using the set interfaces
interface-name disable command before you remove the transceiver. See
“Disconnecting a Fiber-Optic Cable from an EX Series Switch” on page 183.
Optical transceivers
Copyright © 2014, Juniper Networks, Inc.6
EX4600 Switch Hardware Guide
