Juniper EX4600 Series User Manual

Table 14: Rack Requirements for the EX4600 Switch (continued)
GuidelinesRack Requirement
•
Ensure that the rack complies with the standards for a 19-in. or 23-in. rack as defined in Cabinets,
Racks, Panels, and Associated Equipment (documentnumber EIA-310–D) published by the Electronics
Industry Association.
•
A 600-mm rack as defined in the four-partEquipment Engineering (EE); European telecommunications
standard for equipment practice (document numbers ETS 300 119-1 through 119-4) published by
the European Telecommunications Standards Institute
(href="http://www.etsi.org">http://www.etsi.org).
The horizontal spacing between the rails in a rack that complies with this standard is usually wider
than the device's mounting brackets, which measure 19 in. (48.26 cm) from outer edge to outer
edge. Use approved wing devices to narrow the opening between the rails as required.
•
Ensure that the rack rails are spaced widely enough to accommodate the switch chassis’ external
dimensions. The outer edges of the front-mounting brackets extend the width to 19 in. (48.26 cm).
•
The front and rear rack rails must be spaced between 28 in. (71.1 cm) and 36 in. (91.4 cm)
front-to-back.
•
The rack must be strong enough to support the weight of the switch.
•
Ensure that the spacing of rails and adjacent racks allows for proper clearance around the switch
and rack.
Rack size and strength
•
Secure the rack to the building structure.
•
If earthquakes are a possibility in your geographical area, secure the rack to the floor.
•
Secure the rack to the ceiling brackets as well as wall or floor brackets for maximum stability.
Rack connection to
building structure
Related
Documentation
Chassis Physical Specifications for a EX4600 Switch on page 9•
• Rack-Mounting and Cabinet-Mounting Warnings on page 108
• Clearance Requirements for Airflowand Hardware Maintenance for an EX4600 Switch
on page 41
• Mounting an EX4600 Switch in a Rack or Cabinet on page 141
Cabinet Requirements for an EX4600 Switch
You can mount the EX4600 switch in a cabinet that contains a four-post 19-in. rack as
defined in Cabinets, Racks, Panels, and Associated Equipment (document number
EIA-310-D) published by the Electronics Industry Association.
Cabinet requirements consist of:
•
Cabinet size and clearance
•
Cabinet airflow requirements
Table 15 on page 41 provides the cabinet requirements and specifications for the EX4600
switch.
Copyright © 2014, Juniper Networks, Inc.40
EX4600 Switch Hardware Guide
* Optics, Fans and Power supply sold separately for EX4600-40F-S.

Juniper EX4600 Series Specifications

General

Product Series	EX4600
10GbE ports	24 or 48
Cooling	Front-to-back or back-to-front airflow
Rack Units	1 U
Virtual Chassis	Up to 10 members
MAC address table size	288, 000 entries
Memory	8 GB DRAM
Layer 3 Routing	Yes
AC Power Input	100-240V AC
Ports	24 or 48 x 10GbE ports
40GbE ports	4
100GbE ports	0
Power Supply	Dual redundant, hot-swappable AC or DC
Jumbo frames	9216 bytes
Operating temperature	0°C to 45°C
Input voltage	100-240 VAC, -40 to -72 VDC
Operating relative humidity	5% to 90% noncondensing
Fans	Redundant
JUNOS OS	Junos OS
Storage	16 GB flash
DC Power Input	-40 to -72 VDC
