Juniper EX4600 Series User Manual

BEST PRACTICE: Use theEX4600 asamasterandbackupRE inthe Virtual
Chassisbecausethe EX4300 does not support PoweroverEthernet(PoE),
802.1x, and Link Layer Discovery Protocol (LLDP).
Eligible product numbers for Virtual Chassis members are:
•
EX4600
•
EX4300 as a linecard
System Software
EX Series switches use the Junos operating system (OS), which provides Layer 2 and
Layer 3 switching, routing, and security services. Junos OS is installed on a EX4600
switch’s 8-gigabyte (GB) internal flash drive. The same Junos OS code base that runs
on EX4600 switches also runs on all Juniper Networks QFX Series devices, and J Series,
M Series, MX Series, and T Series routers.
For more information about which features are supported on QFX Series devices, see
QFX Series Software Features Overview.
You manage the switch using the Junos OS command-line interface (CLI), accessible
through the console and out-of-band management ports on the device.
Related
Documentation
EX4600 Switch Models on page 5•
• Expansion Modules for the EX4600 on page 19
EX4600 Switch Models
The EX4600 switches have a base configuration of 24 small form-factor pluggable plus
(SFP+) ports and 4 quad small-form-factor pluggable (QSFP+) that can be expanded
by using expansion modules. All switches are available with either AC or DC power supply
and with either airflow-in or airflow-out cooling. In legacy switches, or switches with an
LCD, this air flow is called front-to-back and back-to-front.
Table 3 on page 5 lists the EX4600 switch models.
Table 3: EX4600 Switch Product Numbers
Airflow
Power
Supply
Number of
Expansion
ModulesPortsProduct Number
Air In (FRU to port)AC224 SFP+ and 4 QSFP+
EX4600-40F-AFI
QFX5100-24S-AFI
Air Out (port to FRU)AC224 SFP+ and 4 QSFP+
EX4600-40F-AFO
QFX5100-24S-AFI
Air In (FRU to port)DC224 SFP+ and 4 QSFP+
EX4600-40F-DC-AFI
QFX5100-24S-DC-AFI
5Copyright © 2014, Juniper Networks, Inc.
Chapter 1: EX4600 Overview

Juniper EX4600 Series Specifications

General

Product Series	EX4600
10GbE ports	24 or 48
Cooling	Front-to-back or back-to-front airflow
Rack Units	1 U
Virtual Chassis	Up to 10 members
MAC address table size	288, 000 entries
Memory	8 GB DRAM
Layer 3 Routing	Yes
AC Power Input	100-240V AC
Ports	24 or 48 x 10GbE ports
40GbE ports	4
100GbE ports	0
Power Supply	Dual redundant, hot-swappable AC or DC
Jumbo frames	9216 bytes
Operating temperature	0°C to 45°C
Input voltage	100-240 VAC, -40 to -72 VDC
Operating relative humidity	5% to 90% noncondensing
Fans	Redundant
JUNOS OS	Junos OS
Storage	16 GB flash
DC Power Input	-40 to -72 VDC
