CHAPTER 20
Replacing Components
•
Installing and Removing EX4600 Switch Hardware Components on page 167
•
Installing a Power Supply in an EX4600 Switch on page 168
•
Removing a Power Supply from an EX4600 Switch on page 169
•
Installing an Expansion Module in an EX4600 Switch on page 171
•
Removing an Expansion Module from an EX4600 Switch on page 173
•
Installing a Fan Module in an EX4600 Switch on page 174
•
Removing a Fan Module from an EX4600 Switch on page 176
Installing and Removing EX4600 Switch Hardware Components
The EX4600 switch chassis is a rigid sheet-metal structure that houses the hardware
components. The field-replaceable units (FRUs) in EX4600 switches are:
•
Power supply
•
Fan module
•
Expansion modules
•
SFP+ transceiver
•
QSFP+ transceiver
All of the EX4600 switch FRUs are hot-insertable and hot-removable: you can remove
and replace them without powering off the switch or disrupting switch functions.
CAUTION: Replace a failed power supply with a new power supply within 1
minuteof removal to prevent chassis overheating. Replace a failed fan module
with a new fan within 1 minute of removal to prevent chassis overheating.
To install a power supplyin a EX4600 switch, follow the instructions in “Installing a Power
Supply in an EX4600 Switch” on page 168. To remove a power supply from a EX4600
switch, follow the instructions in “Removing a Power Supply from an EX4600 Switch”
on page 169.
