Table 21: Optical Interface Support for 10-Gigabit Ethernet SFP+ Transceivers for the EX4600

Switch

Specifications

Ethernet

Standard

QFX-SFP-10GE-USRProduct SKU number10GBASE-SR

10 GbpsRate

LCConnector type

DualFiber count

850 nmTransmitter

wavelength

–7.3 dBmMinimum launch

power

–1.3 dBmMaximum launch

power

–11.1 dBmMinimum receiver

sensitivity

–1 dBmMaximuminputpower

AvailableDOM support

MMFMMFMMFFiber type

50/125 µm50/125 µm62.5/125 µmCore/cladding

size

OM3

(OM4 compatible)

OM2OM1Fiber grade

1500 MHz/km500 MHz/km200 MHz/kmModal bandwidth

100 m (328 ft)30 m (98 ft)10 m (32 ft)Distance
