CHAPTER 4
Modules
•
Expansion Modules for the EX4600 on page 19
Expansion Modules for the EX4600
The EX4600 switch has two bays on the port panel for optional expansion modules. The
EX4600 supports two expansion modules to increase port density:
•
EX4600-EM-8F, which provides 8 additional 10-Gigabit Ethernet Enhanced Small
Form-Factor Pluggable (SFP+) ports.
•
QFX-EM-4Q, which provides 4 additional 40-Gigabit Quad SFP+ (QSFP+) ports.
The EX4600 is configured for the QFX-EM-4Q by default, but any combination of the
two modules is supported. Expansion modules can be hot-inserted or hot-removed.
However, when an EX4600-EM-8F is inserted instead of the default QFX-EM-4Q, the
new configuration causes the interfaces to temporarily go down. Likewise when an
EX4600-EM-8F is running on the EX4600 and it is swapped with a QFX-EM-4Q, the
interfaces temporarily go down, which can cause a short disruption in traffic.
NOTE: Expansion modules and transceivers are not shipped with the switch
and must be ordered separately.
•
EX4600-EM-8F on page 19
•
QFX-EM-4Q on page 20
EX4600-EM-8F
The EX4600-EM-8F, provides 8 additional 10-Gigabit Ethernet SFP+ ports to one of the
bays in the EX4600 switch. Figure 9 on page 20 shows the ports and LEDs on the
expansion module.
19Copyright © 2014, Juniper Networks, Inc.

Juniper EX4600 Series Specifications

General

Product Series	EX4600
10GbE ports	24 or 48
Cooling	Front-to-back or back-to-front airflow
Rack Units	1 U
Virtual Chassis	Up to 10 members
MAC address table size	288, 000 entries
Memory	8 GB DRAM
Layer 3 Routing	Yes
AC Power Input	100-240V AC
Ports	24 or 48 x 10GbE ports
40GbE ports	4
100GbE ports	0
Power Supply	Dual redundant, hot-swappable AC or DC
Jumbo frames	9216 bytes
Operating temperature	0°C to 45°C
Input voltage	100-240 VAC, -40 to -72 VDC
Operating relative humidity	5% to 90% noncondensing
Fans	Redundant
JUNOS OS	Junos OS
Storage	16 GB flash
DC Power Input	-40 to -72 VDC
