Juniper EX4600 Series

Table 23: SFP+ Passive Direct Attach Copper Cable Specifications (continued)
SpecificationsProduct Number
10-Gbps full-duplex serial transmissionRateQFX-SFP-DAC-3M
Copper pigtailConnector type
3.3 VSupply voltage
0.015 WPower consumption (per end)
–40
°
C to 85
°
CStorage temperature
TwinaxCable type
30 AWGWire AWG
1 in. (2.54 cm)Minimum cable bend radius
100 ohmsCable characteristic impedance
1% maximumCrosstalk between pairs
4.3 nsec/mTime delay
3 m (9.9 ft)Length
10-Gbps full-duplex serial transmissionRateQFX-SFP-DAC-5M
Copper pigtailConnector type
3.3 VSupply voltage
0.015 WPower consumption (per end)
–40
°
C to 85
°
CStorage temperature
TwinaxCable type
24 AWGWire AWG
1.25 in. (3.2 cm)Minimum cable bend radius
100 ohmsCable characteristic impedance
2% maximumCrosstalk between pairs
4.3 nsec/mTime delay
5 m (16.4 ft)Length
Copyright © 2014, Juniper Networks, Inc.62
EX4600 Switch Hardware Guide
