6. (Optional) Configure the name of the switch. If the name includes spaces, enclose
the name in quotation marks (“ ”).
[edit]
root@# set system host-name host-name
7. Configure the default gateway.
[edit]
root@# set routing-options static route default next-hop address
8. Configure the IP address and prefix length for the switch management interface.
[edit]
root@# set interfaces em0 unit 0 family inet address address/prefix-length
CAUTION: Although the CLI permits you to configure two management
Ethernet interfaces within the same subnet, only one interface is usable
and supported.
NOTE: The management ports, em0 (C0) and em1 (C1) are found on the
management panel of the EX4600 switch.
9. (Optional) Configure the static routes to remote prefixes with access to the
management port.
[edit]
root@# set routing-options static route remote-prefix next-hop destination-ip retain
no-readvertise
10. Enable telnet service.
[edit]
root@# set system services telnet
NOTE: When Telnet is enabled, you cannot log in to the EX4600 switch
through Telnet using root credentials. Root login is allowed only for SSH
access.
11. Commit the configuration to activate it on the switch.
[edit]
root@# commit
Related
Documentation
• Installing and Connecting an EX4600 Switch on page 139
Copyright © 2014, Juniper Networks, Inc.160
EX4600 Switch Hardware Guide

Juniper EX4600 Series Specifications

General

Product Series	EX4600
10GbE ports	24 or 48
Cooling	Front-to-back or back-to-front airflow
Rack Units	1 U
Virtual Chassis	Up to 10 members
MAC address table size	288, 000 entries
Memory	8 GB DRAM
Layer 3 Routing	Yes
AC Power Input	100-240V AC
Ports	24 or 48 x 10GbE ports
40GbE ports	4
100GbE ports	0
Power Supply	Dual redundant, hot-swappable AC or DC
Jumbo frames	9216 bytes
Operating temperature	0°C to 45°C
Input voltage	100-240 VAC, -40 to -72 VDC
Operating relative humidity	5% to 90% noncondensing
Fans	Redundant
JUNOS OS	Junos OS
Storage	16 GB flash
DC Power Input	-40 to -72 VDC
