Setting SAM 4.0 mode
The IP address for SAM 4.0 has been set on SIGMA CONTROL 2 at the factory:
169.254.100.100 and must not be changed. The same applies to Port 2000.
1. Open the 8.1.2.2 <Communication – Ethernet/SIGMA NETWORK – Connections – SAM 4.0>
menu.
2. Use «Up» or «Down» to select the SAM 4.0 active: line.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
8.1.2.2 SAM 4.0
Menu
Status Counter 0
No error
------------------------------
SAM 4.0 active: ☑
Active line
Send
IP address : 169.254.100.100
3. Press «Enter».
The SAM 4.0 active: check box flashes.
4. Press «UP».
The check box is activated.
5. Press «Enter».
The setting is applied.
6. Press the «DOWN» key.
7. Press «Enter».
The currently active operating mode flashes.
8. Use «Up» or «Down» to set the Send/Receive value.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
8.1.2.2 SAM 4.0
Menu
Status Counter 0
No error
------------------------------
SAM 4.0 active: ☑
Send/Receive
Active line
IP address : 169.254.100.100
9. Press the «Enter» key.
The setting is applied.
8 Initial Start-up
8.7 Setting the machine for master control operation
104
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3 No.: 901700 10 E

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
