8.5.1.2 Setting the clock program (example)
When setting a clock programme for the first time, note first the switching times on the "User-
defined clock programme" table for example.
In addition to individual weekdays, the controller has the following cycles:
■ Mon-Thu
■ Mon-Fri
■ Mon-Sat
■ Mon-Sun
■ Sat-Thu
■ Sun-Thu
Example
■ Machine ON: On weekdays 06:30AM – 05:00PM, Fridays 06:30AM – 03:00PM
■ Machine OFF: Sat – Sun and during midday break 12:00PM – 01:00PM
The following switching points result:
No.: Day Time Function
01 Mon-Fri 06:30AM on
02 Mon-Fri 12:00PM off
03 Mon-Fri 01:00PM on
04 Mon-Thu 05:00PM off
05 Fri 03:00PM off
Tab. 62 Example of a machine ON/OFF clock program
Precondition Access level 2 is activated.
1. Open the 6
<Time control>
menu.
2. Use «Up» or «Down» to select the
01
line.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
6 Time control
Menu
······························
01 n.a. 00:00AM off
Active line with switching point 01
02 n.a. 00:00AM off
Switching point 02
03 n.a. 00:00AM off
Switching point 03
04 n.a. 00:00AM off
Switching point 04
05 n.a. 00:00AM off
Switching point 05
3. Press «Enter».
The
n.a.
indication flashes.
4. Use «Up» or «Down» to set the weekdays.
5. Press the «Enter» key.
The setting is applied.
6. Press the «Right» key.
8 Initial Start-up
8.5 Machine start and machine stop
No.: 901700 10 E
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3
83
