5.4.2 Main menu
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
Main menu
----------------English GB----------------
Current language
▶1 Status
Active line
▶2 Performance data
Submenu
▶3 Operating data
Submenu
▶4 Maintenance
Submenu
▶5 Configuration
Submenu
Representation
The main menu is the top menu level. You open the individual submenus in the main menu.
A scrollbar appears at the right side of the display if you open a menu with more than 6 lines. It
represents the currently visible portion of the menu. A short scrollbar thus indicates that the opened
menu is very long as only a small portion can be displayed.
The image above provides an example for the appearance of the main menu (without scrollbar).
Numbering
Each menu is numbered.
Not all menus may be displayed because the access to certain menus is restricted by the access
level, and some menus are displayed or hidden due to specific settings or options.
For example, you can recognise subordinate menus in the menu structure by the number preced‐
ing their designation. The menu structure is explained in chapter 5.7.2.
Active line
The active line (2–8) is always shown as white text on a dark background. In deviation of this, the
header is also shown as white text on a dark background, but cannot be selected.
Press «Enter» to open a menu in the active line. This opens the selected menu.
You change parameters in Setting mode.
5.4.3 Setting parameters
In order to set a parameter in the active line of the selected menu, you must always switch to
setting mode.
Setting parameters
Press «Enter». The value of the parameter will flash indicating that it can be changed.
The «Enter» key affects only the active line.
In some lines, you can change more than one parameter.
In this case, you must first select the specific parameter with the «Left» or «Right» keys.
5 Design and Function
5.4 Display
26
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3 No.: 901700 10 E
