KAESER SIGMA CONTROL 2 Service Manual

6. Press the «Enter» key.
The setting is applied.
7. Press the «Right» key.
8. Press «Enter».
The check box assigned to the input flashes.
9. Press the «Up» key.
The check box is activated.
10. Press «Enter».
The setting is applied.
ok is displayed.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.5 External DI / AII signal
Menu
Idle signal
DI1.09 ☐
······························
Acknowledge messages
DI1.05 ok ☑
Active line with deactivated check box
······························
Result The Remote acknowledgement function is activated.
Activating the remote control
➤ Activate remote control see chapter 8.2.13.
Result The remote control is activated.
Result Should a message occur, it can now be acknowledged from a control centre.
8.10 Error behaviour
The behaviour in the event of a fault during the communication in master control mode or when
receiving measured values from external sensors can be set.
The following options can be displayed and set:
■ Communication
─ SAM 4.0
─ Com-Module
■ Sensor
─ AII1.02 (with access level 2 dispay only)
In the following example, the behaviour in master control mode is set with SAM 4.0 .
Precondition Access level 2 is activated.
8 Initial Start-up
8.10 Error behaviour
No.: 901700 10 E
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3
131

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
