2. Press the «Down» key once.
Output DOR has been selected
3. Press «Enter».
The output of the selected message flashes.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.10.1 DO-functions
Menu
On load
DOR1.05 ok ☐ ¦ Logic : +
Active line with assigned output
······························
Controller on
DOR1.03 ☐ ¦ Logic : +
······························
4. Select a free output with the «Up» or «Down» key.
5. Press «Enter».
The setting is applied.
6. Press the «Right» key.
7. Press «Enter».
The check box will flash.
8. Press «Up» key.
The check box associated to the output is activated.
9. Press «Enter».
If the message is correctly assigned to the output and activated,
ok
is displayed.
10. If necessary, set the
Logic
option.
Result A message about the operational state is now sent via the assigned digital output.
You are missing an organised display of assigned output signals?
➤ Enter the selected output in table 7981.
8.8.2 Output input signals on the display
In addition to the defined alarm and warning messages there are three further freely selectable in‐
put signals that can be used to display messages. A list of the alarm and warning messages is pro‐
vided in chapters 10.2 and 10.3. Please see the machine's wiring diagram for information on free
inputs.
An input signal can be classified as either a fault, a warning or an operational message. To sup‐
press any possible contact bounce or similar problems, the input signal can be delayed by an ad‐
justable period. This ensures that the signal must be apparent for a minimum period before it can
be processed as a message.
If an input signal is classified as fault, the controller goes into the alarm state and shuts down
the machine.
Overview
Use the
External messages
menu for specifying the settings.
■ Enter the message text
■ Assign and activate the input
8 Initial Start-up
8.8 Setting input and output signals
No.: 901700 10 E
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3
121
