KAESER SIGMA CONTROL 2 Service Manual

2. Press «Enter».
The td delay time flashes.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.10.2.1 External message 1
Menu
External message 1
Message text
DI1.07 ok ☑
Input selected
td: 0s ¦ Logic : +
set time delay td
DOR1.04 ☐
Warning ☑
Message type (operational, alarm, warning)
3. Use «Up» or «Down» to set the time delay in seconds.
4. Press «Enter».
Result The td delay time has been set.
8.8.2.5 Setting the logic
Possible logic settings
Message at Sign
24 V +
0 V -
Tab. 80 Logic settings
1. Use «Up» or «Down» to select the td line.
2. Press the «Right» arrow.
3. Press «Enter».
The control field Logic flashes.
4. Use «UP» or «Down» to set the desired behaviour, see table 80.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.10.2.1 External message 1
Menu
External message 1
Message text
DI1.07 ok ☑
Input selected
td: 0s ¦ Logic : +
active line, set logic control field
DOR1.04 ☐
Warning ☑
Message type (operational, alarm, warning)
5. Press «Enter».
Result For messages at 24 V, the logic is set with the + symbol.
8.8.2.6 Setting the message type
1. Select the message type line with the «Up» and «Down» keys.
8 Initial Start-up
8.8 Setting input and output signals
124
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3 No.: 901700 10 E

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
