KAESER SIGMA CONTROL 2 - Menu Overview; Operating Mode; Tab. 39 KAESER CONNECT Functions

Operating element Meaning
Select language: Setting the display language for KAESER CONNECT
System status Menu representation on local display
Graphs ■ Pressures and temperatures are displayed in different graphs
■
Graphic representation of the machine status (STOP, IDLE,
12)
, LOAD)
and speed over the time line
Messages ■ Current messages
■ Event history
I/O display Assignment of the input/output modules
User management ■ Creating and activating new user accounts
■ Modifying or deactivating existing user accounts
■ Changing passwords
Settings ■ Unit display format
■ Date display format
■ Time display format
Backup Saving data via KAESER CONNECT from SIGMA CONTROL 2 to a PC
12)
not for SXC
Tab. 39 KAESER CONNECT functions
Further information For opening KAESER CONNECT, login and other procedures, please see chapter 8.3.
5.7 Menu overview
5.7.1 Operating mode
When the power supply is switched on, details of the software are displayed (for example):
C o m p r e s s o r
Machine model
PN: SN:
Material number and serial number of the machine
EN:
Equipment number of the machine
SIGMA CONTROL 2 – MCS
MCS: Main Control System
PN: y.yyyyyy SN: x.xx.xx
Material number and serial number of the controller
Software: ABC_V.V.V
Software version
Subsequently, the software is loaded and the current operating mode is displayed as a pipe and
instrument diagram. Example:
5 Design and Function
5.7 Menu overview
No.: 901700 10 E
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3
29
