8.4 Displaying and setting the blower properties
This section contains instruction about the display of the blower properties and their settings for the
machine's specific installation elevation.
"Display" means that the parameter will only be shown.
"Setting:" means that the parameter can also be changed.
Parameters Type Explanation
Altitude Setting Input the current installation elevation above base height level (mean
height above sea level).
Air pressure Display The system calculates the value for the air pressure according to the
installation elevation.
Pressure version Display Machine operating mode
■ Pressure
■ Vacuum
Maximum
pressure
Display The machine is designed for this pressure (maximum working pres‐
sure).
Design pressure Display The machine is configured for this pressure.
Minimum
pressure
Display For design reasons, pressure can only be built up above this value
(minimum working pressure).
Tab. 59 Blower characteristics
➤ Set the installation elevation as shown in chapter 8.4.2.
8.4.1 Displaying the blower properties
1. Open the 5.2
<Configuration – Blower properties>
menu.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.2 Blower properties
Menu
Altitude 65m
Active line
Air pressure 1.006bar
Pressure version Pressure
Maximum pressure 0.40bar
Design pressure 0.30bar
Minimum pressure 0.20bar
2. Use «Up» or «Down» to select the line.
8.4.2 Setting the installation elevation
The installation elevation can be set within certain limits:
Precondition Access level 2 is activated.
1. Open the 5.2
<Configuration – Blower properties>
menu.
2. Use «Up» or «Down» to select the
Altitude
line.
8 Initial Start-up
8.4 Displaying and setting the blower properties
80
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3 No.: 901700 10 E
