10. Press «Enter».
The setting is applied.
ok
is displayed.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.5 External DI / AII signal
Menu
▶1 Current signal AII1.02
Load signal
DI1.04 ☐
······························
Idle signal
DI1.09 ok ☑
Active line with deactivated check box
11. Press «Escape» repeatedly to leave this menu.
Result The idle signal is set to remote operation. The conveyed air escapes through the Load/Idle run
valve.
8.5.4.3 Activating the remote control
➤ Activate remote control see chapter 8.2.13.
Result SIGMA CONTROL 2 remote control is activated.
8.6 Operating modes in frequency-controlled machines
You can set various operating modes in frequency-controlled machines. Use the 5.4
Operating
modes
menu for specifying the settings. The selection options for the operating modes depend on
the configuration of the AII1.02 current signal. Set the current signal in the 5.5.1
Current signal
AII1.02
menu (see chapter 8.6.1).
Possible operating modes:
■ Fixed speed
■ Pressure control
■ External speed control
■ External values control
The
Fixed speed
and
Pressure control
operating modes can always be selected, regardless of the
setting of the AII1.02 current signal.
The
External speed control
and
External values control
operating modes are only available if the
AII1.02 current signal has been correspondingly defined.
Relationships concerning operating modes:
■ Fixed speed
─ Target value:
→ Via parameters in the 5.4.1
Fixed speed
menu
8 Initial Start-up
8.6 Operating modes in frequency-controlled machines
No.: 901700 10 E
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3
91
