KAESER SIGMA CONTROL 2 Service Manual

■ Set the time delay
■ Setting the logic
■ Assign and activate the output
■ Selecting the message type
■ Activate the message.
8.8.2.1 External messages menu
Precondition The electrical connection has been made.
Access level 2 is activated.
1. Open the 5.10.2 <Configuration – I/O periphery – External messages> menu.
The External messages menu is displayed.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.10.2 External messages
Menu
▶1 External message 1
Active line with external message No. 1
▶2 External message 2
▶3 External message 3
8.8.2.2 Enter the message text
In the below example we select External message 1 .
1. Use «Up» or «Down» to select the External message 1 line.
2. Press «Enter».
The External message 1 menu is displayed.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.10.2.1 External message 1
Menu
External message 1
Message text
DI1.06 ☐
No input assigned
td: 0s ¦ Logic : +
Logic
DOR1.04 ☐
Warning ☑
Message type (operational, alarm, warning)
3. Press «Enter».
The cursor is located at the first character of the message text.
A column with alphanumeric characters is displayed.
The selected character flashes.
4. Select the required character with the «Up» or «Down» keys.
5. Press the «Right» arrow.
The cursor jumps to the next position of the message text.
6. Enter the remaining characters of the message text in the same manner.
8 Initial Start-up
8.8 Setting input and output signals
122
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3 No.: 901700 10 E

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
