Slave IP configuration
If the controllers of both machines are linked directly, they must be given different IP addresses.
Example:
IP addressController machine 1 (Master mode): 169.254.100.101
IP address Controller machine 2 (Slave): 169.254.100.102
Precondition The electrical connection is made.
Access level 2 is activated.
1. Set IP address for the slave; see chapter 8.2.14,
IP address see above example.
The IP address of machine 2 (slave) is set correctly.
2. Open the 8.1.2.1
<Communication – Ethernet/SIGMA NETWORK – Connections – SIGMA
CONTROL 2>
menu.
3. Use «Up» or «Down» to select the
Mode
line.
4. Press «Enter».
The setting mode is active.
5. Use «Up» or «Down» to set Machine 2
Slave
operating mode.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
8.1.2.1 SIGMA CONTROL 2
Menu
Status Run 1¦Error 0
------------------------------
Mode : Slave
Active line
Port : 2.001
······························
Communication partner
6. Press the «Enter» key.
The setting is applied.
7. Use «Up» or «Down» to select the
IP address
line.
8. Press «Enter».
The setting mode is active.
9. Set the IP address of the communication partner (master, see above example).
10. Press «Enter».
The IP address of machine 1 (master) is set correctly.
Setting the load balancing
Setting the load balancing (see chapter 8.7.4.5).
Activating the remote control
Activate remote control see chapter 8.2.13.
Result The remote control is activated.
The controller of machine 2 is set as slave.
8 Initial Start-up
8.7 Setting the machine for master control operation
118
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3 No.: 901700 10 E
