KAESER SIGMA CONTROL 2 Service Manual

Precondition An SD card with compatible file system (FAT32) and minimum 50 MB free memory is plugged into
the SD card slot X5 of SIGMA CONTROL 2
The write protection of the SD card has been deactivated.
Access level 2 is activated.
1. Open the 5.6 <Configuration – Save data> menu.
2. Use «Up» or «Down» to select the Language: line.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.6 Save data
Menu
Language: en_GB English
Active line
······························
Save data : ☐
······························
Eject SD card : ☐
Status recognised
3. Press «Enter».
The display for the set language flashes.
4. Use «Up» or «Down» to select the desired language.
5. Press «Enter».
The setting is applied.
6. Use «Up» or «Down» to select the Save data line.
4 0 0 m b a r 0 8 : 1 5 A M 8 0 ° C
Header
5.6 Save data
Menu
Language: en_GB English
······························
Save data : ☑
Active line
······························
Eject SD card : ☐
Status recognised
7. Press «Enter».
The check box Save data will flash.
8. Press «Up».
The check box is activated.
9. Press «Enter».
A security query is displayed.
10. Press «Enter».
Result The settings are saved on the SD card.
Safely remove the SD card.
1. Use «Up» or «Down» to select the Eject SD card line.
2. Press «Enter».
The check box Eject SD card will flash.
9 Operation
9.9 Save data
No.: 901700 10 E
Service Manual Controller
SIGMA CONTROL 2 BLOWER ≥ 2.5.3
149

KAESER SIGMA CONTROL 2 Specifications

General

Controller Type	Microprocessor-based
Model	SIGMA CONTROL 2
Manufacturer	KAESER
Input Voltage	24 V DC
Protection Class	IP54
Communication Protocols	Modbus, Profibus
Data Logging	Comprehensive data logging
Remote Monitoring	Yes
Communication Interface	Ethernet
