SCPI Command Reference 5-57
Operation Event Register:
Bits B0 through B3 — Not used.
Bit B4, Measuring (Meas) — Set bit indicates that the instrument is
performing a measurement.
Bit B5, Triggering (Trig) — Set bit indicates that the instrument is in the
Device Action block of the Trigger Model.
Bits B6 through B9 — Not used.
Bit B10, Idle — Set bit indicates that the instruments in the idle state.
Bits B11 through B15 — Not used.
Trig
B14 - B12B15
B11 B10 B9 B8 B7
B6 B5
B4 B1
B0
(2 )
5
32
0 0/1
Bit
Position
Event
Decimal
Weighting
Value
Value : 1 = Operation Event Set
0 = Operation Event Cleared
Events : Idle = Idle state of the 2010
Trig = Triggering
Meas = Measuring
Meas
(2 )
4
16
0/1
Idle
(2 )
10
1024
0/1
B3
B2
Fi
gure
5
-
6
Operation event
register
