General Bus Commands
General Bus Commands and Associated Statements
General commands are those commands, such as DCL, that have the same general meaning
regardless of the instrument. Table 4-3 lists the general bus commands along with the
programming statement for each command, which use the Keithley KPC-488.2 IEEE interface
and the HP- style Universal Language Driver. Note that the commands requiring that the primary
address be specified assume that the address is the factory-set address of 16.
REN (remote enable)
The remote enable command is sent to the Model 2010 by the controller to set up the
instrument for remote operation. Generally, the instrument should be placed in the remote mode
before you attempt to program it over the bus. Simply setting REN true does not actually place
the instrument in the remote state. You must address the instrument to listen after setting REN
true before it goes into remote.
Note that the instrument does not have to be in remote to be a talker.
Program fragment
PRINT #1, "remote 16" 'Place the Model 2010 in remote; turn
on REM annunciator
Note that all front panel controls except for LOCAL and POWER are inoperative while the
instrument is in remote. You can restore normal front panel operation by pressing the LOCAL
key.
IFC (interface clear)
The IFC command is sent by the controller to place the Model 2010 Multimeter in the local,
talker, listener idle states. The unit responds to the IFC command by canceling front panel TALK
or LSTN lights, if the instrument was previously placed in one of those states.
Table 4-3
General bus commands and associated statements
Command Programming statement Effect on Model 2010 Multimeter
REN
IFC
LLO
GTL
DCL
SDC
GET
SPE, SPD
REMOTE 16
ABORT
LOCAL LOCKOUT
LOCAL 16
LOCAL
CLEAR
CLEAR 16
TRIGGER 16
SPOLL 16
Goes into effect when next addressed to listen.
Goes into talker and listener idle states.
LOCAL key locked out.
Cancel remote; restore front panel operation for the 2010.
Cancel remote; restore front panel operation for all devices.
Return all devices to known conditions.
Returns Model 2010 to known conditions.
Initiates a trigger.
Serial Polls the Model 2010.
4-12 Remote Operation

Keithley 2010 Specifications

General

Frequency Range	3 Hz to 300 kHz
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Resistance Accuracy	0.01%
Interface	GPIB, RS-232
Power Supply	50 Hz or 60 Hz
