SPECIFICATIONS
2010 Low-Noise Multimeter
HW 9/5/03
Rev. C
FREQUENCY AND PERIOD CHARACTERISTICS
1,2
RESOLUTION ACCURACY
ACV FREQUENCY PERIOD GATE ±(ppm of 90 Day/1 Year
RANGE RANGE RANGE TIME reading) ±(% of reading)
100 mV 3 Hz 333 ms
to to to 1 s 0.3 0.01
750 V 500 kHz 2 µs
FREQUENCY NOTES
1. Specifications are for square wave inputs only. Input signal must be >10% of ACV range. If input is
<20mV on the 100mV range then the frequency must be >10Hz.
2. 20% overrange on all ranges except 750V range.
TEMPERATURE CHARACTERISTICS
THERMOCOUPLE
2, 3, 4
ACCURACY
1
90 DAY/1 YEAR (23°C ± 5°C)
RELATIVE TO SIMULATED USING
TYPE RANGE RESOLUTION REFERENCE JUNCTION 2001-TCSCAN
5
J –200 to + 760°C 0.001°C ±0.5°C ±0.65°C
K –200 to +1372°C 0.001°C ±0.5°C ±0.70°C
N –200 to +1300°C 0.001°C ±0.5°C ±0.70°C
T –200 to + 400°C 0.001°C ±0.5°C ±0.68°C
4-WIRE RTD
2, 3, 7, 8
90 DAY/1 YEAR 2 YEAR
(23°C ± 5°C) (23°C ± 5°C)
RANGE RESOLUTION ACCURACY
6
ACCURACY
6
–100° to +100°C 0.001°C ±0.08°C ±0.12°C
–200° to +630°C 0.001°C ±0.14°C ±0.18°C
Temperature Notes
1. For temperatures <–100°C, add ±0.1°C and >900°C add ±0.3°C.
2. Temperature can be displayed in °C, K or °F.
3. Accuracy based on ITS-90.
4. Exclusive of thermocouple error.
5. Specifications apply to channels 2–6. Add 0.06°C/channel from channel 6.
6. Excluding probe errors.
7. 100Ω platinum, D100, F100, PT385, PT-3916 or user type.
8. Maximum lead resistance (each lead) to achieve rated accuracy is 5Ω.
INTERNAL SCANNER SPEED
MAXIMUM INTERNAL SCANNER RATES: RANGE: CHANNELS/s
1
TRIGGER DELAY = 0
2 WIRE 4 WIRE T/C RTD
DCV
2
ACV
2, 3
OHMS
2
OHMS
2
TEMPERATURE
2
TEMPERATURE
2
All : 105 All : 96 All : 102 <10MΩ : 55 All : 70 All : 2
TRIGGER DELAY = AUTO
2 WIRE 4 WIRE T/C RTD
DCV
2
ACV
2, 3
OHMS
2
OHMS
2
TEMPERATURE
2
TEMPERATURE
2
0.1 V : 100 All : 1.8 100 Ω : 82 100 Ω : 42 All : 70 All : 2
1 V : 100 1 kΩ : 85 1 kΩ : 42
10 V : 100 10 kΩ : 42 10 kΩ : 25
100 V : 70 100 kΩ : 28 100 kΩ : 21
1000 V : 70 1 MΩ : 8 1 MΩ : 7
10 MΩ : 5 10 MΩ : 5
100 MΩ : 3 100 MΩ : 3
Internal Scanner Speed Notes
1. Speeds are for 60Hz or 50Hz operation using factory default operating conditions (*RST). Auto Zero off,
Auto Range off, Display off, sample count = 1024.
2. NPLC = 0.01.
3. DETector BANDwidth: 300.
Triggering and Memory
READING HOLD SENSITIVITY: 0.01%, 0.1%, 1%, or 10% of reading.
TRIGGER DELAY: 0 to 99 hrs (1ms step size).
EXTERNAL TRIGGER DELAY: <1ms.
EXTERNAL TRIGGER JITTER: <500µs.
MEMORY: 1024 readings.
Math Functions
Rel, Min/Max/Average/StdDev (of stored reading), dB, dBm, Limit Test,
%, and mX+b with user defined units displayed.
dBm REFERENCE RESISTANCES: 1 to 9999Ω in 1Ω increments.
REMOTE INTERFACE
Keithley 199/196 Emulation
GPIB (IEEE-488.2) and RS-232C
SCPI (Standard Commands for Programmable Instruments)
GENERAL
POWER SUPPLY: 100V / 120V / 220V / 240V.
LINE FREQUENCY: 50Hz to 60Hz and 440Hz, automatically sensed at
power-up.
POWER CONSUMPTION: 22VA.
OPERATING ENVIRONMENT: Specified for 0°C to 50°C. Specified to
80% R.H. at 35°C. Altitude up to 2000 meters.
STORAGE ENVIRONMENT: –40°C to 70°C.
WARRANTY: 3 years.
SAFETY: Conforms to European Union Directive 73/23/EEC
EN61010-1, CAT II.
EMC: Complies with European Union Directive 89/336/EEC,
EN61326-1.
VIBRATION: MIL-PRF-28800F Class 3 Random.
WARMUP: 2 hours to rated accuracy.
DIMENSIONS:
Rack Mounting: 89mm high × 213mm wide × 370mm deep (3
1
⁄ 2 in ×
8
3
⁄ 8 in × 14
9
⁄ 16 in).
Bench Configuration (with handle and feet): 104mm high ×
238mm wide × 370mm deep (4
1
⁄ 8 in × 9
3
⁄ 8 in × 14
9
⁄ 16 in).
SHIPPING WEIGHT: 5kg (11 lbs).
VOLT HERTZ PRODUCT: ≤8 × 10
7
V·Hz.
ACCESSORIES SUPPLIED: Model 1751 Safety Test Leads, User
Manual, Service Manual.
Specifications are subject to change without notice.
SPEC-2010
ACCESSORIES AVAILABLE
1050 Padded Carrying Case with handle and should strap
1754
Universal Test Lead Kit
2000-SCAN 10-Channel Scanner
2001-TCSCAN 9-Channel Thermocouple Scanner
(includes 1-channel reference junction)
2010-EW 1-Year Warranty Extension
4288-1 Single Fixed Rack Mount Kit
4288-2 Dual Fixed Rack Mount Kit
5804
4 Terminal Test Lead Set
5805 Kelvin Probes
5806 Kelvin Clip Lead Set
5807-7 Helical Spring Point Test Leads
7007-1 Shielded GPIB Cable, 1m (3.2 ft)
7007-2 Shielded GPIB Cable, 2m (6.5 ft)
7009-5 Shielded RS-232 Cable 1.5m (5 ft)
8502 Trigger Link Adapter to 6 female BNC connector
8503
Trigger Link Cable to 2 Male BNCs, 1m (3.2 ft.)
8605 High Performance Modular Test Leads
8606 High Performance Probe Tip Kit
