EOI and bus hold-off K0
K1
K2
K3
Enable EOI and bus hold-off on X
Disable EOI, enable bus hold-off on X
Enable EOI, disable bus hold-off on X
Disable both EOI and bus hold-off on X
Terminator Y0
Y1
Y2
Y3
CR LF
LF CR
CR
LF
Status U0
U1
U2
U3
U4
U5
U6
Send machine status word (199 format only)
Send error conditions (only supports no scanner, IDDC,
IDDCO)
Send Translator word list (since Translator is not sup-
ported, replies with one space character)
Send buffer size
Send current value of “V” (199 format, equivalent to U7
for 196)
Send input switch status (front /rear) (199 format,
equivalent to U8 for 196)
Send simulated temperature (set by H0)
Multiplex A0
A1
Auto/Cal multiplex disabled
Auto/Cal multiplex enabled
Delay Wn n=delay period in milliseconds, (0ms to 999999ms)
Display Da
D
Display up to 12-character message (a=character)
Cancel display mode
Table D-1 (cont.)
Models 196/199 device-dependent command summary
Mode Command Description
D-4 Models 196/199 Commands
