Introduction
The IEEE-488.2 standard requires specific information about how the Model 2010
implements the standard. Paragraph 4.9 of the IEEE-488.2 standard (Std 488.2-1987) lists the
documentation requirements. Table F-1 provides a summary of the requirements and provides
the information or references the manual for that information. Table F-2 lists the coupled
commands used by the Model 2010.
The Model 2010 complies with SCPI version 1991.0. Table 5-2 through Table 5-11 list the
SCPI confirmed commands and the non-SCPI commands implemented by the Model 2010.
Table F-1
IEEE-488 documentation requirements
Requirements Description or reference
(1)
(2)
(3)
(4)
(5)
(a)
(b)
(c)
(d)
(e)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
(16)
(17)
(18)
(19)
(20)
(21)
(22)
(23)
IEEE-488 Interface Function Codes.
Behavior of 2010 when the address is set outside the
range 0-30.
Behavior of 2010 when valid address is entered.
Power-On Setup Conditions.
Message Exchange Options:
Input buffer size.
Queries that return more than one response message
unit.
Queries that generate a response when parsed.
Queries that generate a response when read.
Coupled commands.
Functional elements required for SCPI commands.
Buffer size limitations for block data.
Syntax restrictions.
Response syntax for every query command.
Device-to-device message transfer that does not
follow rules of the standard.
Block data response size.
Common Commands implemented by 2010.
Calibration query information.
Trigger macro for *DDT.
Macro information
Response to *IDN (identification).
Storage area for *PUD and *PUD?
Resource description for *RDT and *RDT?
Effects of *RST, *RCL and *SAV.
*TST information.
Status register structure.
Sequential or overlapped commands.
Operation complete messages.
See Appendix E.
Cannot enter an invalid address.
Address changes and bus resets.
Determine by :SYSTem:POSetup (Section 5).
256 bytes.
None.
All queries (Common Commands and SCPI).
None.
See Table F-2.
Contained in SCPI command subsystems tables
(see Table 5-2 through Table 5-11).
Block display messages: 12 characters max,
See Programming Syntax in Section 4.
See Programming Syntax in Section 4.
None.
See Display Subsystem in Section 5.
See Common Commands in Section 4.
Not applicable.
Not applicable.
See Common Commands in Section 4.
Not applicable.
Not applicable.
See Common Commands in Section 4.
See Common Commands in Section 4.
See Status Structure in Section 4.
All are sequential except :INIT and :INIT:CONT
ON, which are overlapped.
*OPC, *OPC? and *WAI; see Common Commands
in Section 4.
F-2 IEEE-488 and SCPI Conformance Information
