Calculate subsystem
The commands in this subsystem are used to configure and control the
Calculate subsystems and are summarized in Table 5-2.
:CALCulate[1]
These commands are used to configure and control the MXB (polynomial)
and percent math calculations. Detailed information on math calculations is
provided in Section 2.
:FORMat <name>
CALCulate[1]:FORMat <name> Specify CALC1 format
Parameters <function> = NONE No calculations
MXB Polynomial math calculation
PERCent Percent math calculation
Query :FORMat? Query programmed math format
Table 5-11
UNIT command summary
Command Description
Default
parameter
SCPI
:UNIT
:TEMPerature <name>
:TEMPerature?
:VOLTage
:AC <name>
:DB
:REFerence <n>
:REFerence?
:DBM
:IMPedance <n>
:IMPedance?
:AC?
[:DC] <name>
:DB
:REFerence <n>
:REFerence?
:DBM
:IMPedance <n>
:IMPedance?
:DC?
Select temperature measurement units (C, F, or K).
Query temperature units.
Path to configure voltage units.
Select ACV measurement units (V, DB or DBM).
Path to set DB reference voltage.
Specify reference in volts (1e-7 to 1000).
Query DB reference.
Path to set DBM reference impedance.
Specify reference impedance (1 to 9999).
Query DBM reference impedance.
Query ACV units.
Select DCV measurement units (V, DB, or DBM).
Path to set DB reference voltage:
Specify reference in volts (1e-7 to 1000).
Query reference.
Path to set DBM reference impedance:
Specify reference impedance (1 to 9999).
Query reference impedance.
Query DCV units.
C
V
1
75
V
1
75
√
√
√
5-20 SCPI Command Reference

Keithley 2010 Specifications

General

Frequency Range	3 Hz to 300 kHz
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	3 A
DC Current Accuracy	0.05%
AC Current Range	3 A
Resistance Accuracy	0.01%
Interface	GPIB, RS-232
Power Supply	50 Hz or 60 Hz
