Section 1 Basic Printer Functions 1-18
4. Pressing down on the Lever (3), insert the Roll Spool (2) to the core of new roll paper.
5. Install the Roll Spool with new roll paper to the
Roll Deck.
6. Insert the leading edge of roll paper under the Guide Plate (8) until the edge touches the
feeding roller. Then rotate the Paper Feeding Knob (9) clockwise so that the feeding rollers
catch the roll paper.
3
2
NOTE
Be careful of the winding direction of the roll paper at this time.
8
9
