DETAILED CONTROLS AND GAUGES OPERATION

3-144

3. After loosening hexagonal screw (11) of the grease level

sensor, lift up limit switch (12), remove cap (13), then

remove spring (14).

4. Remove 2 wing nuts (15).

5. Lift up grease can cover (16) vertically to remove it.

6. Remove follower plate (17) from the center of the grease

can.
