Maintenance
Lubrication ( ):
12
(Note: lubricate more frequently when in heavy-duty operation!)
• Hinges, joints and fittings (e.g. door arresters)
● ●● ●
• Rear axle oscillating bearing
● ● ●● ●
• Front and rear axle planetary drive bearings (left and right)
● ● ●● ●
• Loader unit –seeLubricating the loader unit, lift, tilt and lock rams on page 5-20
• Lift frame bearing
● ● ●● ●
• Tilt rod bearing
● ● ●● ●
• Tilt lever bearing
● ● ●● ●
• Lift ram bearing
● ● ●● ●
• Tilt ram bearing
● ● ●● ●
• Quickhitch: bearing on lift frame
● ● ●● ●
Functional check ( ):
Check the function of the following assemblies/components. Rectify if necessary:
• Service and parking brake
● ● ● ●● ● ●
• Steering system
● ● ● ●● ● ●
• Lights and electrical system
● ● ● ●● ● ●
• Air conditioning (option)
● ● ● ●● ● ●
5.24 Maintenance plan
Work description
For service and maintenance work on the attachment, please refer to the operation and maintenance manual of the
attachment manufacturer as well.
Work-
shop
Operator/driver Workshop
Delivery
inspection
Maintenance work
(once a day)
“A”
every 20 s/h
“A”
every 50 s/h
1st Inspection
1
at 100 s/h
“B”
every 500 s/h
2
2nd Inspection
“C”
every 1500 s/h
once a year
