KYMCO MXU 500 - Spark Arrester

SPARK ARRESTER
Be sure the exhaust pipe and muffler are cool
before cleaning the spark arrester.
1. Remove the three bolts (1), the spark arrester
(2) and the gasket (3) from the muffler.
118
(1)
(1) Bolts
(2) Spark arrester (3) Gasket
(3)
(2)
