KYMCO MXU 500 - Torque Values

1. GENERAL INFORMATION
1-11
MXU 500
TORQUE VALUES
STANDARD TORQUE VALUES
Item
Torque
kgf-m (N-m, lbf-ft)
Item
Torque
kgf-m (N-m, lbf-ft)
5mm bolt and nut
6mm bolt and nut
8mm bolt and nut
10mm bolt and nut
12mm bolt and nut
14mm bolt and nut
0.5 (5, 3.6)
1 (10, 7.2)
2.2 (22, 16)
3.5 (35, 25)
5.5 (55, 40)
7 (70, 50)
4mm screw
5mm screw
6mm screw, SH bolt
6mm flange bolt and nut
8mm flange bolt and nut
10mm flange bolt and nut
0.3 (3, 2.2)
0.4 (4, 2.9)
0.9 (9, 6.5)
1.2 (12, 9)
2.7 (27, 20)
4 (40, 29)
Torque specifications listed below are for important fasteners.
ENGINE
Item Q‘ty
Thread dia.
(mm)
Torque
kgf-m (N-m, lbf-ft)
Remarks
MAINTENANCE:
Spark plug
Tappet ADJ nut
Engine oil filter cap
Engine oil filter cartridge
Engine drain plug
LUBRICATION SYSTEM:
Oil pump screw
Oil pipe bolt
COOLING SYSTEM:
Water pump bolt
Fan motor bolt
Fan motor switch
1
4
1
1
1
1
2
2
4
1
10
5
30
20
12
4
16
6
5
16
1.2 (12, 8.6)
0.9 (9, 6.5)
1.5 (15, 11)
1 (10, 7.2)
2.5 (25, 18)
0.3 (3, 2)
3.5 (35, 25.2)
1.3 (13, 9)
0.53 (5, 2.8)
1.8 (17, 13)
Apply oil
Apply oil
Apply oil
(Cont’d)
