46
(1)
(1) Accessory socket
(2) Cap
ACCESSORY SOCKET
The accessory socket (1) is attached to the left
side of the meter cover. You can use the
accessory socket to power a trouble light,
spotlight, radio, or cell phone, etc.
Do not plug in any heat-generating accessory
such as an automobile cigarette lighter
because it can damage the socket.
Be carful not to flood this accessory socket
when washing your ATV.
CAUTION:
To use the accessory socket:
1. Turn the ignition switch ON, then start the
engine.
2. Turn the headlights OFF.
3. Open the accessory socket cap (2), and then
insert the accessory power plug into the
socket.
Be sure the engine is on and the headlights are
turned off before using the accessory socket,
otherwise you may drain the battery.
The accessory socket’s rated capacity is DC
12V, 120 Watts (10A) or less. If you exceed this
limit, you may blow a fuse.
When you are done using an accessory, unplug
it, and cover the socket with the cap.
(2)
