16. BRAKE SYSTEM
16-4
MXU 500
BRAKE PADS REPLACEMENT
FRONT BRAKE PADS
Remove the front wheel. (
refer to the
“
FRONT WHEEL
REMOVAL/INSPECTION/
INSTALLATION
” section in the chapter
14
).
Remove the two brake pad pins from the
brake caliper.
Remove the two mounting bolts from brake
caliper and then remove brake caliper.
Compress the brake caliper holder and
remove brake pads.
Ɣ Do not operate the brake lever during
or after brake pad removal.
Ɣ Replace the brake pads as a set,
otherwise braking performance will be
adversely affected.
＊
