3. INSPECTION/ADJUSTMENT
3-22
MXU 500
BRAKE FLUID INSPECTION
Check if the fluid level is below the lower
level mark through the inspection window.
HEADLIGHT AIM
Turn the ignition switch ON and start the
engine.
Turn on the headlight switch.
Adjust the headlight aim by turning the
headlight aim adjusting screws.
Inspection Window (R/L Brake Lever)
Inspection Window (Rear Brake Pedal)
Adjust Screws
