13. DRIVE TRAIN
13-5
MXU 500
FRONT DRIVE SHAFT
DISASSEMBLY/INSPECTION/
ASSEMBLY
DISASSEMBLY
Remove the front drive shaft (refer to the
“FRONT DRIVE SHAFT
REOMVAL/INSPECTION/
INSTALLATION” section in this chapter)
Remove the boot band of the case side joint.
Slide the boot toward the center of the front
drive shaft and remove the circlip from the
case side joint.
Separate the case side joint from the front
drive shaft.
Band
Case Side Join
To Next Page
