KYMCO MXU 500 - Wheels;Tires

3. INSPECTION/ADJUSTMENT
3-25
MXU 500
WHEELS/TIRES
Check the tires for cuts, imbedded nails or
other damages.
Check the tire pressure.
TIRE PRESSURE
1 Rider
Front 0.28 kgf/cm² (28 Kpa, 3.2 psi)
Rear 0.28 kgf/cm² (28 Kpa, 3.2 psi)
TIRE SIZE
Front : 25X8-12
Rear : 25X10-12
Check the front axle nut for looseness.
Front Axle Nu
t
Tire pressure should be checked when
tires are cold.
＊
The threads on both rod-end must be of
the same len
g
th.
＊
