KYMCO MXU 500 - Specifications; General Information

1. GENERAL INFORMATION
1-2
MXU 500
SPECIFICATIONS
Model No. LAA0
Name & Type MXU 500
Overall length 2203 mm (88.12 in)
Overall width 1223 mm (48.92 in)
Overall height 1240 mm (49.6 in)
Wheel base 1293 mm (51.72 in)
Engine type O.H.C.
Displacement 498.5 cm
3
(30.48 cu-in)
Fuel used 92# nonleaded gasoline
Front wheel 154 kg (338.8 lbs)
Rear wheel 134 kg (294.8 lbs)
Dry weight
Total 288 kg (633.6 lbs)
Front wheel 164 kg (360.8 lbs)
Rear wheel 144 kg (316.8 lbs)
Curb weight
Total 308 kg (648 lbs)
Front wheel
25X8-12
Tires
Rear wheel
25X10-12
Ground clearance 235 mm (9.4 in)
Min. turning radius 3350 mm (134 in)
Starting system
Electric/Recoil
starter
Type Gasoline, 4-stroke
Cylinder arrangement Single cylinder
Combustion chamber type Semi-sphere
Valve arrangement O.H.C., chain drive
Bore x stroke
92X75 mm
(3.68X3 in)
Compression ratio 10.5:1
Compression pressure
15 kgf/cm²
(1500kPa, 213 psi)
Opens 5q BTDCIntake valve
(at 1mm lift)
Closes 45q ABDC
Opens 45q BBDCExhaust valve
(at 1mm lift)
Closes 5q ATDC
Intake 0.1 mm (0.004 in)Valve clearance
(cold)
Exhaust 0.1 mm (0.004 in)
Idle speed (rpm) 1500 rpm
Cooling type Liquid cooled
Lubrication type
Forced pressure &
Wet sump
Oil pump type Trochoid
Oil filter type Full-flow filtration
Oil capacity
3.6 L (3.17 lmp qt,
3.82 Us qt)
Oil exchanging capacity
3 L (2.64 lmp qt,
3.18 Us qt)
After draining and oil
filter cartridge change
3.2 L (2.82 lmp qt,
3.39 Us qt)
Air cleaner type & No Wet type element
Fuel capacity
17 L (3.57 lmp gal,
4.42 US gal
Type CVK
ON ROAD #128Main
jet
OFF ROAD #130
Slow jet #40
Choke jet #90
Type
Full transistor digital
ignition
Ignition timing 5q/1500 rpm
Spark plug CR7E (NGK)
Spark plug gap
0.6阡0.7mm
(0.024阡0.028 in)
Battery Capacity 12V18AH
Clutch type
Wet, centrifugal
automatic
Clutch operation system Automatic (V-belt)
Primary reduction system V-belt
Secondary reduction
system
Shaft drive
High reduction ratio
3.76
Low reduction ratio
6.464
Reverse ratio
5.31
FR/RR tire rolling
circumference
1995/1995 mm
(79.8/79.8 in)
Front
Tire pressure
Rear
0.28 kg/cm²
(28 Kpa, 3.2 psi)
Left 36q
Turning angle
Right 36q
Front Disk brake
Brake system type
Rear Disk brake
Front Double wishbone
Suspension type
Rear Link suspension
Frame type Double cradle
Engine
I
g
nition S
y
stem
Drive Train
Moving Device
Lubrication System
Fuel S
y
stem
Carbureto
r
Electrical Equipment
