6. COOLING SYSTEM
6-18
MXU 500
RADIATOR RESERVE TANK
REMOVAL
Remove the front fender (refer to the
“FRAME COVERS” section in the
chapter 2).
Remove the two mounting bolts and then
remove the radiator reserve tank from
frame.
Open the reserve tank cap and drain the
coolant from the reserve tank.
Disconnect the siphon hose.
INSTALLATION
Installation is in the reverse order of
removal.
Pour the recommended coolant to the upper
level line with the center stand applied
Siphon Hose
To Next Page
