KYMCO MXU 500 - Fuel Tank Cap; Fuel Valve

FUEL TANK CAP
page 53.
After refueling, be sure to tighten the fuel tank
cap until it clicks.
Insert the breather tube into the meter cover
hole.
To refuel refer to
(1) Fuel tank cap
(2) Breather tube
(3) Meter cover hole
(1)
(2)
(3)
FUEL VALVE
The fuel valve supplies fuel from the fuel tank to
the carburetor. The fuel valve has three
positions.
(1) Fuel valve
(1)
39
