5. FUEL SYSTEM
5-20
MXU 500
PAIR SOLENOID VALVE
REMOVAL/INSTALLATION
Disconnect air supply hose and vacuum hose
from the air solenoid valve, then remove the
air solenoid valve from frame.
Installation is in the reverse order of
removal.
Vacuum Hose
Air Supply Hose
PAIR Solenoid Valve
