Drive select lever adjustment
1. Turn the ignition switch is ON and make sure
the engine stop.
2. Remove 3 fasteners (1), then remove the left
side cover (2).
50
(2)
(1) Fasteners
(2) Left side cover
3. Loosen the locknuts (3) of rod (4). Shift the
gear to neutral by moving the shift lever
and/or turn the rod. (The neutral indicator
lamp comes on.)
(4)
(3) Lock nuts
(4) Rod
(3)
(1)
