19. STARTER SYSTEM
19-4
MXU 500
(From previous page)
xPoorly connected terminal
xPoorly connected starter motor cable.
xOpen circuit in starter motor cable.
xFaulty starter motor.
xLoose or disconnected starter motor cable.
xFaulty starter MAG.
xFaulty brake light switch.
xLoose or poor contact of connector.
xOpen or short circuit in wire harness.
(Go to following page)
Abnormal
Starter moto
r
does not turn
N
ormal
Abnormal
N
ormal
Check for loose or poorly
connected starter MAG
terminals.
Abnormal
Check for loose or poorly
connected or broken starter
motor cable.
N
o clicks
Clicks
With the ignition switch
turned to “ON”, push the
starter switch and check for a
click sound from the starter
MAG.
Connect the starter motor terminal
directly to the battery positive
terminal (Because a large amount of
current flows, do not use a thin wire).
Starter motor turns
N
ormal
Check the starter relay coil
ground line (page 19-6)
