19. STARTER SYSTEM
19-5
MXU 500
(From previous page)
xFaulty engine stop switch (OFF ROAD).
xFaulty starter switch.
xLoose or poor contact of connector.
xOpen circuit in wire harness.
xFaulty starter MAG.
xLoose or poor starter relay connector contact.
Battery voltage registers
N
o volta
g
e
Check the starter MAG
voltage (page 19-7).
Abnormal
Check the starter relay for a
click sound from the starter
relay. (page 19-6).
N
ormal
