1. GENERAL INFORMATION
1-12
MXU 500
Item Q‘ty
Thread dia.
(mm)
Torque
kgf-m (N-m, lbf-ft)
Remarks
CYLINDER HEAD:
Cylinder head bolt
Cylinder head bolt
Cylinder head nut
Cylinder head cover
Breather separator bolt
Cam chain tensioner bolt
Tensioner sealing bolt
Rocker arm shaft
Chain guide pivot bolt
Water joint bolt
CYLINDER:
Cylinder bolt
DRIVE/DRIVEN PULLEY:
Drive pulley nut
Wet clutch nut
Driven pulley nut
Driven pulley assembly plate nut
TRANSMISSION:
Crankcase bolt
Drive bevel gear nut
Driven bevel gear nut
Stopper lever bolt
Stopper lever boss nut
Shift came stopper plug
Output shaft bearing nut
Drive shaft bearing bolt
STARTER SYSTEM:
Starter pulley nut
4
9
2
4
3
2
1
2
2
2
2
1
1
1
1
19
1
1
1
1
1
1
4
1
10
8
6
6
6
6
10
18
8
6
6
20
25
16
36
6
20
20
8
12
20
85
8
14
4.8 (48, 34.6)
2.3 (23, 17)
1 (10, 7)
1 (10, 7)
1.3 (13, 9)
1.2 (12, 8.6)
1 (10, 7)
4.5 (45, 32.4)
2 (20, 15)
1.2 (12, 8.6)
1 (10, 7.2)
14 (140, 100.8)
14 (140, 100.8)
10 (100, 72)
7.5 (75, 54)
1.2 (12, 8.6)
14 (140, 100.8)
14 (140, 100.8)
2.5 (25, 18)
3 (30, 21.6))
4.8 (48, 35)
11 (110, 79.2)
3 (30, 21.6)
5.5 (55, 40)
Apply oil
Apply oil
Apply oil
Apply oil
Apply oil
Apply oil
Apply oil
Apply oil
Apply oil
